“Low Impedance, High Capacity, and Compact Design: YMIN’s Liquid SMD Aluminum Electrolytic Capacitors Promote the Development of Electronic Rearview Mirrors”

The Camera Monitor System (CMS) for electronic rearview mirrors is a product combination based on cameras and displays that enhances the driver’s visual perception of the vehicle’s surroundings and rear sides, further improving driving safety and comfort.

The electronic rearview mirror operates by replacing traditional optical side mirrors with a combination of cameras and monitors. The display mode involves external cameras capturing images, processing them, and displaying them on a screen inside the cabin.

The circuit diagram of the electronic rearview mirror includes a motor drive circuit and a control circuit. The motor drive circuit consists of several components, including a motor, a capacitor, a resistor, and a switch. In the electronic rearview mirror, the capacitor and resistor work to balance the operation of the motor. The capacitor helps the motor store electrical energy, allowing it to maintain stability during changes in rotational speed.

Capacitor Selection

Advantages:

Low impedance, high capacity, dedicated for high-end power supply
105℃ 3000~8000H
Compliant with AEC-Q200 ROHS directive

Liquid chip aluminum electrolytic capacitors perfectly solve the rearview mirror problem

YMIN liquid chip aluminum electrolytic capacitors have the advantages of low impedance, high capacity, small size, and flatness, providing support for the design and development of domestically produced, miniaturized and innovative electronic rearview mirrors.
